850-120VAC

产品型号：850-120VAC 产品名称：850-120VAC 产品分类：Special Controls 品牌：Time Mark Corporation（美国时间标记公司） 产品简介：The Model 850 Two Hand Control Module is designed to be used with two palm or push-button switches, which must be closed within 0.5 seconds of each other to operate machinery. As long as both switches are pressed, the relay will remain energized in the continuous mode. For applications requiring a pulse to initiate operations, the Model 850 can be set to produce a pulse output by connecting a resistor to pins 4 and 7. The resistor value in ohms should be 100,000 times the desired time in seconds (R=100,000 x T). The internal relay de-energizes on completion of the pulse, even if both switches are depressed. The relay also will de-energize immediately, if either hand switch is released, in standard or pulsed mode. The compact size of the Two-Hand Control Module allows installation into an existing control panel. It can be used with any type of machinery requiring safe, two-handed operation such as presses, punches, cutters, etc. The standard nominal supply voltages are 120VAC, 240VAC, or 24VAC at 50/60 Hz. , or 24VDC. 技术参数：Contacts: SPDT; Mount: 11-Pin; Voltage Range: 105-135VAC 应用领域：适用于特殊工业控制需求，包括定制化控制方案、专用监测设备、特殊功能继电器等 产品特点：美国原装进口，品质可靠；DIN导轨安装，方便集成；LED状态指示，直观易读；宽电压范围，适应性强；工业级设计，经久耐用
