663

产品型号：663 产品名称：663 产品分类：Liquid Level Controls 品牌：Time Mark Corporation（美国时间标记公司） 产品简介：The Model 663 Pump Down Control, part of the 600 series line of instrumentation controls, is designed to monitor and maintain liquid levels. A user-provided 4-20mA current loop represents the liquid level. The HIGH ADJUST setpoint, and the LOW ADJUST setpoint, are field adjustable. If the input rises above the high setpoint, the PUMP DOWN relay energizes, and remains that way until the input falls below the low set point. Top-mounted LEDs on the Model 663 show system status. The PUMP DOWN LED turns ON when the input is above the high setpoint, and goes OFF when the input is below the low setpoint. The HIGH ALARM condition indicator turns ON if the input rises to 10% above the high setpoint. The HIGH ALARM condition then resets when the input is again less than 10% above the high setpoint. For proper operation, the high setpoint must always be set above the low setpoint. An INPUT LOOP ERROR LED turns ON if the input is outside the 4-20mA range. A Time Mark Model 650 Loop Power Supply (or equivalent) is required to provide the 24 VDC operating voltage. Also, a Time Mark Model 672-15 Pressure Transducer (or equivalent) is required to provide the input signal. 技术参数：Voltage Range: 24VDC 应用领域：适用于水箱液位控制、泵阀自动控制、工业储罐液位监测、给排水系统等液位控制场景 产品特点：美国原装进口，品质可靠；DIN导轨安装，方便集成；LED状态指示，直观易读；宽电压范围，适应性强；工业级设计，经久耐用
