16-1-H-S

产品型号：16-1-H-S 产品名称：16-1-H-S 产品分类：Voltage & Frequency Monitors 品牌：Time Mark Corporation（美国时间标记公司） 产品简介：The Model 16-1-X-X protects equipment from Over, Under, Over/Under voltage or rapid cycling conditions that can damage valuable equipment. Trip and restart delays are adjustable, or can be disabled. Input voltage ranges are 12-30 VAC/VDC or 30-277 VAC/VDC. The 8-pin plug-in has 2 SPDT relays, while the surface mount case has 1 SPDT relay. See Ordering Information for details. 8-pin plug-in versions require an 8-pin socket, such as Time Mark’s Model 51X120. A proprietary microcontroller-based sensing circuit deenergizes the relay(s) after the trip delay (if enabled) upon detection of harmful voltage conditions. The relay(s) will energize after power line conditions return to an acceptable level and the restart delay time has expired (if enabled). Trip delays can be added to avoid nuisance tripping while restart delays can be used to stagger the startup of equipment or protect compressors. Time Mark’s proprietary microcontroller-based design offers maximum flexibility with an easy to use interface. 技术参数：Contacts: SPDT; Mount: Surface Mount; VF Function: Over and Under , Over or Under; Voltage Range: 30-277VAC/VDC 应用领域：适用于电源质量监测、过压欠压保护、频率监测、发电机控制、UPS系统等电力质量监测场景 产品特点：美国原装进口，品质可靠；DIN导轨安装，方便集成；LED状态指示，直观易读；宽电压范围，适应性强；工业级设计，经久耐用
